Lime is a calcium-containing inorganic mineral composed primarily of oxides, and hydroxide, usually calcium oxide and/ or calcium hydroxide.Limestone is extracted from quarries or mines. Part of the extracted stone, selected according to its chemical composition and optical granulometry, is calcinated at about 1,000 °C (1,830 °F) in different types of lime kilns to produce quicklime according to the reaction:
1 | % of Available CaO | 82 -85 | 80±2 (For AAC Blocks) |
2 | % Total CaO | 88% min. | 85% min. |
3 | % Acid Insoluble as SiO2 | 1.5 (Max.) | 2.0 (Max.) |
4 | % MgO | 2.0 (Max.) | 2.5 (Max.) |
5 | % R2O3 | 0. 5 (Max.) | 0.5 (Max.) |
6 | Mesh (BSS) | 97-98% passing through 250 mesh | 90-95% passing through 170 mesh |
7 | Reactivity Time 55°C | 15-20 minutes | 20- 30 minutes |
8 | Packing | Once used Jumbo Bag/ PP/HDPE bag |
Grades | A | B | C | D | E | F |
---|---|---|---|---|---|---|
% of Available Lime as Ca(OH)2 | +90 | +85 | +80 | +75 | +70 | +65 |
% of Available Lime as CaO | +68 | +64 | +60 | +56 | +52 | +49 |
% Acid Insolubles (Max.) | 1.0 | 1.5 | 3.0 | 4.0 | 4.5 | 6.0 |
% Iron as Fe | <0.035 | <0.040 | <0.050 | <0.055 | <0.060 | <0.060 |
% Magnesia as MgO | 1.25 | 1.5 | 2 | 2 | 2.5 | 2.5 |
Mesh (BSS) | 250 | 200 | 200 | 150 | 150 | 150 |
Packing | PP/HDPE Bag & Jumbo Bag |
